Real-Time Forest Fire & Smoke Detection System using UAV Drone

Jetson Nano YOLOv11 TensorRT MAVLink Python

An end-to-end AI-powered drone system for early forest fire detection and autonomous response

Demo Video

Ho Chi Minh City University of Technology and Engineering (HCMUTE) - Graduation Thesis 2025

Table of Contents

Problem Statement

Forest fires cause devastating environmental damage, loss of wildlife habitats, and threaten human communities. Traditional fire detection methods rely on:

  • Satellite imaging: Low temporal resolution (hours delay)
  • Fixed cameras/sensors: Limited coverage area
  • Human patrols: Expensive, dangerous, and inefficient

Challenge: How can we detect forest fires in real-time with precise geolocation and immediate alerts to enable rapid response?

Solution Overview

We developed an autonomous UAV-based fire detection system that combines:

  1. Edge AI Processing: YOLOv11 models optimized with TensorRT FP16, running directly on NVIDIA Jetson Nano onboard the drone
  2. Two-Stage Cascaded Detection: Smoke detection (early warning) followed by fire confirmation (reduces false positives)
  3. Real-Time Data Fusion: AI detection results + GPS coordinates + drone telemetry = geo-tagged alerts
  4. Autonomous Response: Automatic mission pause (LOITER mode) when smoke detected, allowing operator to assess the situation
  5. Multi-Channel Alerts: Instant Telegram notifications with images and Google Maps location links

System Overview

Key Technical Highlights

1. Edge AI Optimization (TensorRT FP16)

  • Converted YOLOv11 models from ONNX to TensorRT engines with FP16 precision
  • Achieved 10+ FPS inference on Jetson Nano 4GB (power-constrained edge device)
  • Custom TensorRT inference wrapper with CUDA stream management for asynchronous processing

2. Two-Stage Cascaded Detection Pipeline

Frame Input -> [Stage 1: Smoke Model] -> Smoke Detected?
                                              |
                                   YES        |        NO
                                    v         v
                        [Stage 2: Fire Model]   Continue monitoring
                                    |
                              Fire Confirmed?
                                    |
                          YES       |       NO
                           v        v
                    FIRE ALERT   SMOKE WARNING
  • Stage 1 (Smoke): Continuous inference at full FPS, lightweight model (416x416 input)
  • Stage 2 (Fire): Triggered only when smoke detected, higher precision model (640x640 input)
  • Benefits: Reduces computational load, minimizes false positives, enables early warning

3. Real-Time MAVLink Integration

  • Direct communication with Pixhawk 6C flight controller via pymavlink
  • Autonomous mode switching (GUIDED -> LOITER -> GUIDED) based on AI detection
  • Mission planning with waypoint actions (Takeoff, Land, RTL, Loiter, Delay)
  • Real-time telemetry streaming (GPS, altitude, attitude, battery, speed)

4. Non-Blocking Telegram Alert System

  • Background worker thread for sending alerts without blocking inference
  • Rate limiting to prevent alert spam (configurable cooldown)
  • Image attachment with bounding box overlays and detection confidence
  • GPS coordinates with clickable Google Maps links

5. Multi-Process Architecture

  • Main Process: Smoke detection + RTSP/MJPEG streaming
  • Fire Worker Process: Separate CUDA context for fire confirmation (avoids GPU memory conflicts)
  • Flask Server Thread: Web interface and API endpoints
  • Telegram Worker Thread: Non-blocking alert delivery

System Architecture

Hardware Connection Diagram

Hardware Connection Diagram

Subsystem Components Connection
Vision Pi Camera V2 (IMX219) -> Jetson Nano MIPI CSI-2
Flight Control GPS M10 -> Pixhawk 6C -> Air Telemetry UART
Power 4S LiPo -> PM02 -> PDB DC 14.8V
Propulsion Pixhawk -> ESC 40A x4 -> Motors PWM
Ground Station Laptop -> Ground Telemetry Radio USB

Software Architecture

Software Architecture

Jetson Nano (Onboard - Python 3.6.9):

  • jetson_rtsp_server_v2.py: GStreamer-based RTSP server with H.264 hardware encoding
  • jetson_yolo11_two_stage_mjpeg_server_v5_4_telegram.py: Two-stage AI detection pipeline

Ground Station (Windows/Linux - Python 3.11):

  • webgcs_loiter.py: Flask + SocketIO web-based Ground Control Station with mission planning

Cascaded AI Detection Workflow

Cascaded AI Detection Workflow

Auto Loiter Workflow

Auto Loiter Workflow

When smoke is detected during an autonomous mission:

  1. Detection: Jetson Nano detects smoke with confidence above threshold
  2. Alert: System sends immediate Telegram alert with GPS location
  3. Pause: GCS commands Pixhawk to enter LOITER mode via MAVLink
  4. Hold Position: Drone hovers at current location for operator inspection
  5. Resume/RTL: Operator can resume mission or trigger Return-To-Launch

Data Fusion (AI + Pixhawk)

Data Fusion

Experimental Results

Final Hardware Product

Final Hardware Product

The complete drone system with all components integrated and ready for field testing.

Smoke Detection Alert (Telegram)

Smoke Alerts via Telegram

When smoke is detected, the system immediately sends a Telegram alert with:

  • Detection confidence percentage
  • Bounding box visualization
  • Timestamp
  • GPS coordinates (when available)

Smoke Detection (Ground Control Station)

Smoke Alerts via GCS

The Web GCS displays real-time detection status with live video feed and telemetry data.

Fire Confirmation Alert (Telegram)

Fire Confirmation via Telegram

When fire is confirmed (Stage 2), an urgent alert is sent with higher priority notification.

Fire Confirmation (Ground Control Station)

Fire Confirmation via GCS

The Web GCS shows fire confirmation with captured snapshots and detection history.

Web UI (Ground Control Station)

Web UI

Telegram Alert System Flow

Telegram Alert System

Alert Features:

  • Immediate notification when smoke/fire detected
  • GPS coordinates with Google Maps link
  • Detection frame with bounding boxes
  • Rate limiting to prevent alert spam

Hardware Components

Component Specification Purpose
NVIDIA Jetson Nano 4GB RAM, Maxwell GPU (128 CUDA cores) Edge AI inference
Pi Camera V2 IMX219, 8MP, MIPI CSI-2 Video capture
Pixhawk 6C STM32H7, ArduPilot Copter 4.x Flight control
GPS M10 u-blox M10, 10Hz update Position tracking
433MHz Telemetry Air + Ground pair MAVLink communication
4S LiPo Battery 14.8V, 5000mAh Power supply
ESC 40A x4 3-Phase brushless Motor control

Software Components

Dependencies

Jetson Nano:

  • Python 3.6.9
  • TensorRT 8.x (pre-installed with JetPack)
  • PyCUDA
  • OpenCV 4.x
  • Flask
  • GStreamer (RTSP server)

Ground Station:

  • Python 3.11+
  • Flask + Flask-SocketIO
  • pymavlink
  • requests

File Structure

.
├── jetson_rtsp_server_v2.py          # RTSP H.264 streaming server
├── jetson_yolo11_two_stage_mjpeg_server_v5_4_telegram.py  # AI detection pipeline
├── webgcs_loiter.py                  # Web Ground Control Station
├── stage1_smoke.onnx                 # Smoke detection model (ONNX)
├── stage2_fire.onnx                  # Fire detection model (ONNX)
├── requirements.txt                  # Python dependencies
└── docs/images/                      # Architecture diagrams

Installation & Usage

1. Clone Repository

git clone https://github.com/khangle2101/Real-Time-Fire-Smoke-Detection-Drone.git
cd Real-Time-Fire-Smoke-Detection-Drone

2. Jetson Nano Setup

# Install system dependencies
sudo apt-get update
sudo apt-get install -y gstreamer1.0-rtsp gstreamer1.0-plugins-good \
    gstreamer1.0-plugins-bad python3-gi python3-gst-1.0

# Install Python packages
pip3 install flask opencv-python numpy requests

# Convert models to TensorRT (on Jetson Nano)
trtexec --onnx=stage1_smoke.onnx --saveEngine=stage1_smoke.engine --fp16
trtexec --onnx=stage2_fire.onnx --saveEngine=stage2_fire.engine --fp16

3. Ground Station Setup

# Create virtual environment
python -m venv venv
source venv/bin/activate  # Linux/macOS
# venv\Scripts\activate   # Windows

# Install dependencies
pip install -r requirements.txt

4. Run the System

On Jetson Nano:

# Terminal 1: Start RTSP Server
python3 jetson_rtsp_server_v2.py --width 1280 --height 720 --fps 10

# Terminal 2: Start AI Detection Server
python3 jetson_yolo11_two_stage_mjpeg_server_v5_4_telegram.py \
    --smoke-engine stage1_smoke.engine \
    --fire-engine stage2_fire.engine \
    --rtsp rtsp://127.0.0.1:8554/fire \
    --telegram-token "YOUR_BOT_TOKEN" \
    --telegram-chat "YOUR_CHAT_ID"

On Ground Station:

python webgcs_loiter.py

5. Access Web Interfaces

Service URL Description
Web GCS http://localhost:5000 Drone control & mission planning
MJPEG Stream http://<JETSON_IP>:5002/video_feed Live detection video
Detection API http://<JETSON_IP>:5002/api/status JSON status endpoint

API Reference

Detection Server (Jetson Nano)

GET /api/status

Returns current detection status with smoke/fire confidence, bounding box count, and timestamps.

GET /video_feed

MJPEG video stream with real-time detection overlays.

GET /snaps/snap_<n>.jpg

Fire detection snapshots (n = 0, 1, 2) with bounding box annotations.

Web GCS (Ground Station)

POST /api/missions

Create a new mission with waypoints and actions.

POST /api/mission/start_sequence

Start mission execution with automatic waypoint navigation.

POST /api/mission/resume_after_smoke

Resume mission after smoke detection pause.

GET /api/mission/smoke_pause_status

Get current smoke pause status and location.

Demo Video

Demo Video

Click to watch the full demonstration video

Authors

Graduation Thesis Project - HCMUTE 2025

Name Role Contribution
Le Hoang Khang Team Leader System architecture, AI pipeline, Edge optimization, Web GCS, Hardware integration, Drone assembly, Flight testing
Nguyen Viet Khue Member Flight testing, Web GCS

Acknowledgments

License

This project is distributed under the MIT License. See LICENSE file for more information.

Built for forest fire prevention and environmental protection
