MG Dynamic Navigation (MGDN) is an Unreal Engine plugin that gives AI the ability to move reliably on moving platforms, such as ships, elevators, floating islands, physics-driven actors, and multi-deck structures.
Instead of relying on the static Recast NavMesh, MGDN dynamically builds a local 3D voxel navigation grid, detects walkable areas using raycasts, and runs a custom A* solver to generate paths.
AI movement is handled through smooth local-space spline motion, unaffected by platform rotation, acceleration, or physics simulation.
Typical use cases:
- AI movement on large ships with multiple decks
- AI walking on rotating/tilting platforms
- Physics-driven moving platforms
- Complex ship layouts with ramps, slopes, and multi-layer geometry
A demo with integrated plugin in action with physics moving ship can be found below a link. MG Dynamic Navigation Demo UE5 Project
If you encounter any issues, please open a GitHub issue.
If you'd like to contribute, feel free to create a pull request.
- Dynamic 3D voxel grid generation per moving actor
- Works on any moving/physics actor (ships, elevators, rigs, etc.)
- Local-space A* pathfinding
- Support for ramps, slopes, multi-deck layouts
- Lightweight avoidance system (sphere-trace based) with automatic detour generation
- Grid visualization tools
- Fully Blueprint-callable movement functions
- No dependency on UE’s built-in NavMesh
 |
 |
|---|---|
| Navmesh data point generations and visualization. | Multi-deck navigation paths and spline components. |
 |
|---|
| Dynamic navigation on a physics-driven platform. |
 |
|---|
| Direct move in and out of platforms with same system. UE Navmesh to MGDN |
 |
|---|
| Simple avoidance and re-pathing spline moves with additional stop movements. |
Install the plugin like any other Unreal Engine plugin:
- Place the plugin under:
YourProject/Plugins/MGDynamicNavigation - Enable the plugin in the Unreal Editor
- Add the MGDNNavVolume actor to your moving platform
- Assign or create a MGDNNavDataAsset
- Click Bake Grid
After you enabled the plugin,
- Add MGDN Nav Volume component to your moving platform.
- Adjust the volume size to cover walkable areas.
- Create a new MGDNNavDataAsset and assign it to the component.
- Place your moving platform in the scene.Make sure you have a NavMesh on your scene and walkable geometry is present and ready for navigation.
- Press Btn Bake Grid optionally adjust cell sizes to match your needs.to generate the voxel grid. This may take a few seconds depending on the geometry size. This simply uses the NavMesh to generate the voxel grid into a data asset.
- Press visualize grid button to see the voxel grid.
- Use MGDN movement functions to move the ai or any controller over the platform.
- MGDN movement functions are available in C++ and Blueprint and uses dynamical pathfinding creating splines over the voxel grid uneffected by platform rotation, speed, movement or any other factors enabling.
- A Nav Volume Component defines a 3D bounding box around a moving platform (ship, elevator, vehicle, etc.).
- When you press Bake, the plugin:
- Divides the volume into a 3D voxel grid.
- Line traces each voxel against the Unreal NavMesh.
- Marks voxels as walkable / not walkable and stores them in a data asset.
- During gameplay, the runtime system:
- Detects which platform the AI is currently standing on.
- Converts world-space positions to platform-local coordinates.
- Performs 3D A pathfinding* on the voxel grid.
- Outputs a sequence of grid points that form a valid path.
- A spline is generated locally on the platform:
- The spline is corrected against the real platform surface using per-point sphere traces for accurate Z placement, including slopes and stairs.
- Spline moves with the platform (no drifting).
- AI follows the spline smoothly with rotation and interpolation.
- Physics interactions are suppressed during movement to avoid pushing or destabilizing the platform.
- When AI reaches the goal:
- Spline is destroyed.
- Physics/collision is restored.
- Callback event fires.
- Defines the scanning bounds
- Generates voxel grid from geometry & navmesh
- Stores baked results in MGDNNavDataAsset
- Provides debug visualization tools
- Cell Size – Horizontal voxel resolution
- Cell Height – Vertical voxel slice resolution
- Source Asset – Assigned nav data asset
- Visualize Grid – Shows walkable voxels
- Bake Now – Regenerates grid
- Manages all MGDN volumes in the world
- Handles AI movement updates
- Provides async pathfinding interface
- Allows querying paths in C++ or Blueprint
MGDN moves AI using:
- Local-space spline path
- Smooth interpolation
- Directional rotation
- Optional velocity injection for animation playback
Movement remains stable even if the ship tilts or rotates. MGDN also includes a simple avoidance system: AI perform a forward sphere-trace to detect other pawns and inject a temporary detour point into the spline. When avoidance is triggered, MGDN optionally freezes the actor briefly to prevent oscillation and ensures the detour path remains centered inside the platform bounds.
MG Dynamic Navigation (MGDN) is a technical proof-of-concept (TPOC) that demonstrates how to build
a localized navigation system on top of Unreal's standard NavMesh.
It is designed to solve navigation on moving platforms such as ships, elevators, transports, dynamic floors,
and other actors that reposition or rotate in the world.
MGDN combines two systems:
-
Unreal Engine NavMesh sampling
During baking, MGDN reads the UE NavMesh inside the volume using line traces.
This gives accurate walkable data for any dynamic platform surface. -
Localized grid + custom movement
Navigation is solved in platform-local space using a 3D voxel grid and A* pathfinding.
AI follows this path via a spline that moves with the platform.
This approach ensures the AI stays correctly aligned with the platform without drifting.
MGDN includes a minimal deterministic avoidance layer.
When another pawn is detected in the forward trace:
- A detour point is added to the spline
- A new local path is computed
- The AI optionally freezes movement to prevent rapid oscillation This system is intentionally simple and designed as a foundation that can be extended per-project.
Because MGDN is a TPOC, the movement layer is intentionally minimal.
Depending on your game's movement rules, you may extend or customize the following:
-
C++ movement injection
MGDN uses a lightweight XY interpolation + spline following.
You can replace this with custom character movement logic, root motion, or your own animation-driven locomotion. -
Spline generation
You can modify spline smoothing, point interpolation, or generate curved/bezier paths instead of linear grid paths. -
Onboarding / Offboarding between systems
MGDN does not currently implement transitions between:- Unreal’s native NavMesh navigation, and
- MGDN’s localized navigation on moving platforms.
If your game requires AI to walk from the world onto the platform (or vice-versa), you will need to implement a custom handover:
- Detect approach distance to platform
- Switch from UE navigation → MGDN navigation
- Or reverse when leaving the platform
These features are intentionally left open so each project can implement the best solution for its gameplay style.
MGDN is a flexible base system that:
✔ Bakes local walkable data on moving platforms
✔ Performs 3D grid pathfinding in local space
✔ Moves AI with splines that follow the platform
✔ Allows developers to expand movement logic however they want
But it does not impose a single complete game-ready solution.
This keeps the plugin lightweight, extensible, and easy to adapt to different project needs.
Can MGDN handle multiple decks?
Yes. The voxel grid supports full 3D navigation with multiple height layers.
Does it work with physics-driven platforms?
Yes. Movement is relative to the platform’s transform every frame.
Is Unreal’s NavMesh required?
No. MGDN works entirely without UE NavMesh.
How do I debug walkable nodes?
Use the Visualize Grid button inside MGDN Nav Volume.
- Extremely thin geometry requires smaller cell size
- Path smoothing depends on grid density
- Physics collisions on AI may affect the platform
- Avoid tiny cell heights unless necessary
- Avoidance is intentionally lightweight and may require tuning for dense crowds
- Surface Z detection uses traces; extremely noisy geometry may require adjusting trace height/radius
This plugin is under the MIT License.
Commercial use is allowed as long as the copyright notice is included.
